Jacket Inner and outer PVC
Voltage 300V
Armour Aluminum Armoured
Armour Aluminum Armoured
Temperature -40°C to 105°C
Approvals CSA/CMG FT4, HLBCD, UL1581
Colour Code Blue/Orange
| Cond. Size & Strand | Shield/Coverage | Insul. Type | Nom. OD (Inches) | Nom. Vel. of Prop. | Nom. Cap (pF/ft) A/B | Weight (lbs/mft) | Product Code | Qty/Meters | |
|---|---|---|---|---|---|---|---|---|---|
| 18 (1 PR) 7x26 TC | AL/Polyester 100% | PO | 0.59 | 66% | 45 | 220 | 36123076A |
