Conductor Bare copper
Jacket Overall PVC Max.
Voltage 350V
Nominal Impedance 75 ohms
Approvals EU CMG FT4
Applications CCTV plus audio, pan and tilt CCTV control
Twisted Pair Colours Black & Red
| AWG | Strand & Cond. | Shield / Coverage | Insulation | Insul. NOm. OD Inches (mm) | Nom. OD Inches (mm) | Nom. Cap (pF/ft) | Weight (lbs/mft) | Product Code | Qty/Meters | |
|---|---|---|---|---|---|---|---|---|---|---|
| 20 (CX) | Solid BC | 95% BCB | FPE | 0.145 (3.68) | 0.232 x 0.460 (5.89 x 11.68) | 16.3 | 60 | 35S591802 | ||
| 18 (1 PR) | 7/W BC | Unshielded | PP | 0.066 (1.68) | 0.232 x 0.460 (5.89 x 11.68) | 22.5 | 60 | 35S591802 |
